Socket weld flanges provide secure connections for small-bore pipes (≤DN80). The socket weld flange design allows easy pipe insertion before fillet welding, ideal for steam lines and instrumentation. ASME B16.5 socket weld flanges handle up to 2500 psi.
Made from forged stainless steel, socket weld flanges resist thermal fatigue in cyclic systems. Their compact profile makes socket weld flanges suitable for confined spaces. Pair socket weld flanges with high-yield-strength bolts for vibration-prone setups.
| DN10 (3/8 ") | DN15 (1/2 ") | DN20 (3/4 ") | DN25 (1 ") | DN40 (1-1/2 ") |
| DN50 (2 ") | DN80 (3 ") | DN100 (4 ") | DN125 (5 ") | DN150 (6 ") |
| DN200 (8 ") | DN250 (10 ") | DN300 (12 ") | DN350 (14 ") | DN400 (16 ") |
| DN450 (18 ") | DN500 (20 ") | DN550 (22 ") | DN600 (24 ") |
